Mimo Monitors - Mimo MBS-1080C-OF
10.1" Diagonal Class LCD flat panel display - interactive digital signage - with touchscreen (multi touch) 1280 x 800
Mimo Monitors
MBS-1080C-OF
N/A
0810020600353
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Mimo MBS-1080C-OF 10.1" LCD flat panel display - for digital signage / interactive communication |
| Product Type | LCD flat panel display with touchscreen (multi touch) |
| Diagonal Class | 10.1" |
| Commercial Use | Yes - interactive digital signage |
| Resolution | 1280 x 800 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| Connectivity | Wi-Fi (optional), Bluetooth (optional) |
| PC Interface | VGA (HD-15) |
| Technology | IPS |
| Image Aspect Ratio | 16:10 |
| TV Tuner | No tuner |
| Commercial Features | HTML5 support, Real-Time Clock (RTC), IP Streaming Support |
| Supported Memory Cards | microSD, SDHC Memory Card, SDXC Memory Card, microSDHC, microSDXC |
| USB | Yes |
| Power Consumption Operational | 24 Watt |
| Manufacturer Warranty | 1-year warranty |
| General | |
| Product Type | LCD flat panel display |
| Power Consumption Operational | 24 Watt |
| Diagonal Class | 10.1" |
| Commercial Use | Yes - interactive digital signage |
| Combined With | Touchscreen (multi touch) |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| PC Interface | VGA (HD-15) |
| Design | Open Frame |
| Cooling System | Fanless |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, CEC |
| Power | |
| Power Device | Power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 122 °F |
| Display | |
| LCD Display Technology | IPS |
| Resolution | 1280 x 800 |
| Image Aspect Ratio | 16:10 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Image Contrast Ratio | 800:1 |
| Brightness | 350 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 170° |
| Touchpoints Qty | 10 |
| Response Time | 14 ms |
| Commercial Features | HTML5 support, Real-Time Clock (RTC), IP Streaming Support |
| Additional Features | Capacitive touch technology, 10-bit support, built-in BrightSign media player |
| Connections | |
| Connector Type | USB 2.0 ¦ HDMI output ¦ GPIO ¦ RS-232 ¦ Infrared input/output ¦ LAN ¦ Audio line-out ¦ SPDIF output |
| Remote Control | |
| Features | Snapshot function |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi (optional), Bluetooth (optional) |
| LAN Protocol | Fast Ethernet |
| Digital TV Tuner | |
| MPEG Profiles and Levels | H.264/H.265 |
| Stands & Mounts | |
| Flat Panel Mount Interface | 75 x 75 mm |
| VESA Compatibility | Yes |
| Media Player | |
| Supported Video Formats | MPEG-4, MKV, MOV, VOB, TS, M2TS |
| Supported Audio Formats | MP3, WAV, AC3, AAC, MP2 |
| Supported Pictures Formats | BMP, JPG, PNG |
| Supported Memory Cards | microSD, SDHC Memory Card, SDXC Memory Card, microSDHC, microSDXC |
| USB Port | Yes |
| USB Ports Qty | 1 |
